Sahib Data Model

Entities schema without translation table

Saheb Mobile App - Database Schema

1. Entity Schema (Main Tables - No Translation Table)

All main tables with their columns. Translation relationships shown in diagram 2.

2. Translation Schema (Translation Relationships Only)

Shows how the global translations table relates to content tables.

Translation Strategy

• Location tables (regions, countries, subregions): Use JSON translations column
• Content tables (acts, sermons, resources, qas, adhkars, sermon_paragraphs): Use global translations table
• Fallback chain: Requested language → Record's default_language → Global default (en-US)

Drizzle Query Examples

Basic Translation Query

import { db } from '@/src/db';
import { acts, translations } from '@/src/db/schemas';
import { eq, and, sql, inArray } from 'drizzle-orm';

// Get act title in specific language
async function getActTitle(actId: string, languageCode: string) {
  const result = await db
    .select({
      id: acts.id,
      title: translations.translatedValue,
    })
    .from(acts)
    .innerJoin(translations, and(
      eq(translations.entityType, 'acts'),
      eq(translations.entityId, acts.id),
      eq(translations.fieldName, 'title'),
      eq(translations.languageCode, languageCode)
    ))
    .where(eq(acts.id, actId))
    .limit(1);

  return result[0]?.title || null;
}

Helper Function: Reusable Translation Getter

// Generic helper for any entity type
async function getTranslatedValue(
  entityType: 'acts' | 'sermons' | 'resources' | 'qas' | 'adhkars' | 'sermon_paragraphs',
  entityId: string,
  fieldName: string,
  requestedLanguage: string,
  recordDefaultLanguage: string,
  globalDefaultLanguage: string = 'en-US'
): Promise<string | null> {
  // Try requested language first
  let translation = await db
    .select()
    .from(translations)
    .where(and(
      eq(translations.entityType, entityType),
      eq(translations.entityId, entityId),
      eq(translations.fieldName, fieldName),
      eq(translations.languageCode, requestedLanguage)
    ))
    .limit(1);

  if (translation[0]) return translation[0].translatedValue;

  // Fallback to record's default language
  if (recordDefaultLanguage && recordDefaultLanguage !== requestedLanguage) {
    translation = await db
      .select()
      .from(translations)
      .where(and(
        eq(translations.entityType, entityType),
        eq(translations.entityId, entityId),
        eq(translations.fieldName, fieldName),
        eq(translations.languageCode, recordDefaultLanguage)
      ))
      .limit(1);

    if (translation[0]) return translation[0].translatedValue;
  }

  return null;
}

// Usage example
const act = await db.select().from(acts).where(eq(acts.id, 'act-1')).limit(1);
const title = await getTranslatedValue(
  'acts',
  'act-1',
  'title',
  'fr-FR', // User's current language
  act[0].defaultLanguage, // Record's default (e.g., 'ar-MA')
  'en-US' // Global default
);

Design Notes

• Pure Translation Approach: All languages stored in translations table (including English)
• Per-Record Fallback: Each record has default_language for fallback when requested translation missing
• Location Tables: Use JSON translations column (prepopulated data)
• Content Tables: Use global translations table (dynamic content)

3. Scheduling & Event Bus Schema

schedules {
  target_type: 'act' | 'notification' | 'reminder' | 'other'  // What to schedule
  target_id: integer                                           // ID of the target
  recurrence_type: 'daily' | 'weekly' | 'monthly' | 'yearly'  // How often
  interval: integer                                            // Every N periods
  start_at: integer                                            // When to start
  timezone: string                                             // Timezone context
  is_active: boolean                                           // Enable/disable
}

// Example: Schedule on Monday, Wednesday, Friday
schedule_weekdays: [
  { schedule_id: 1, weekday: 1 }, // Monday
  { schedule_id: 1, weekday: 3 }, // Wednesday
  { schedule_id: 1, weekday: 5 }, // Friday
]

// Example: Schedule on January 1st every year
schedule_yearly: {
  schedule_id: 3,
  month: 1,  // January
  day: 1
}

schedule_runs {
  schedule_id: integer
  scheduled_for: integer      // When it was supposed to run (timestamp)
  executed_at: integer        // When it actually ran (null if not yet)
  status: 'pending' | 'success' | 'failed' | 'skipped' | 'cancelled'
  error_message: string       // If failed
}

interface ScheduleExecution {
  schedule: Schedule;
  executionTime: number; // Unix timestamp in seconds
  targetType: 'act' | 'notification' | 'reminder' | 'other';
  targetId: number;
}
/**
 * Get all schedules that need to be executed within a time range
 *
 * @param rangeStart - Start of the time range (Unix timestamp in seconds)
 * @param rangeEnd - End of the time range (Unix timestamp in seconds)
 * @param timezone - Optional timezone for calculations (defaults to UTC)
 * @returns Array of schedule execution records with calculated execution times
 */
async function getSchedulesInRange(
  rangeStart: number,
  rangeEnd: number,
  timezone: string = 'UTC'
): Promise<ScheduleExecution[]>

const now = Math.floor(Date.now() / 1000);
const in15Minutes = now + (15 * 60); // 15 minutes later

const schedules = await getSchedulesInRange(now, in15Minutes);

// Execute immediately if any schedules found
if (schedules.length > 0) {
  console.log(`Executing ${schedules.length} schedules now...`);
  for (const execution of schedules) {
    await executeSchedule(execution);
  }
}

// Schedule for Isha prayer (daily at 8:15 PM)
const ishaSchedule = {
  id: 5,
  target_type: 'reminder',  // Prayers use 'reminder' type
  target_id: 1,  // ID of the prayer reminder/notification
  recurrence_type: 'daily',
  interval: 1,
  start_at: 1234567890,
  timezone: 'Africa/Casablanca',
  is_active: true,
};

// Schedule times: Isha at 8:15 PM (73500 seconds = 20:15:00)
const ishaTimes = [
  { schedule_id: 5, time_seconds: 73500 },
];

// Act with schedule (daily Quran reading at 8:00 PM)
const quranActSchedule = {
  id: 8,
  target_type: 'act',
  target_id: 15,  // Act ID
  recurrence_type: 'daily',
  interval: 1,
  start_at: 1234567890,
  timezone: 'Africa/Casablanca',
  is_active: true,
};

const quranTimes = [
  { schedule_id: 8, time_seconds: 72000 }, // 20:00:00
];

// Usage: Get schedules for next hour (7:30 PM - 8:30 PM)
const now = Math.floor(Date.now() / 1000);
const oneHourLater = now + 3600;

const schedules = await getSchedulesInRange(now, oneHourLater);

// Results:
// - Isha prayer (schedule_id: 5) at 8:15 PM
// - Quran act (act_id: 15) at 8:00 PM
